Hot sale plastic rotomolding machine water tank make machine with CE certification

The rotational molding process is a high-temperature, low-pressure plastic-forming process that uses heat and bi-axial rotation to produce hollow, one-piece parts.

During the heating stage, the mould slowly rotates in two planes (bi-axial rotation).
The process consists of four distinct phases:

• Loading a measured quantity of polymer (usually in powder form) into the mould.
• Heating the mould in an oven while it rotates, until all the polymer has melted and adhered to the mould wall. The hollow part should be rotated through two or more axes, rotating at different speeds, in order to avoid the accumulation of polymer powder.
• Air cooling the mould. The polymer must be cooled so that it solidifies and can be handled safely by the operator. The part will shrink on cooling, coming away from the mould, and facilitating easy removal of the part.
• Removal of the part.

Production Process:
1, according to customer demand, we determine efficient and reliable equipment technical information (including drawings, data, models and configurations)
2, waiting for the customer to determine the solution we provide, sign the legal document (supply contract) if the joint discussion plan is consistent
3, according to customer needs, we began to arrange equipment production, cutting, welding, assembly, and factory commissioning according to technical drawings.
4. Inform the customer to come to the factory acceptance equipment after the commissioning of our factory equipment is completed.
5. After the equipment is qualified, the equipment will be disassembled, packaged, and the container will be loaded and transported to the port.
6. The customer arranges the factory personnel to arrive at the customer's site within one week after receiving the equipment to guide installation, commissioning, production and training.
7, complete the entire service of the device

Equipment advantages:

1. The oven adopts an inner circular oven structure, which has high space utilization and is more energy-saving.
2, the oven uses a fabricated structure, an oven is divided into 4 or 5 and 6 pieces of assembly
3, the heating method adopts the principle of hot gas going up, heating faster, high efficiency, more energy saving
4, the burner is imported from the Italian Liya Road brand
5, the control system uses Siemens S7-1200 network cable communication method to collect data, reduce the problem of conventional lines, the line laying is more beautiful
6, low-voltage electrical appliances using Germany Schneider configuration, more stable and durable
7, the whole machine is equipped with a remote maintenance module, and the operation of all equipment far away overseas can be viewed through the Internet at the Yingchuang Rotational Plastic Factory.
8, and all motors are equipped with Siemens variable frequency control to improve the service life and age of the motor and reducer, and the gearbox adopts domestic famous brand heavy-duty gearbox
9, the operation mode is fool-like operation, simpler
10, all transmission parts are geared, more stable, efficient, and the service life is longer.
11, Yingchuang Rotomolding accepts the personal customization and design of all customers, and determines the final requirements of customers according to the needs of customers, so that customers are satisfied, we can rest assured
